Winoco Blast Chiller-Freezer

RM 28,600.00


  • Product Dimension:
  • Packaging Dimension: 820*880*1160mm
  • Material: Stainless steel
  • Voltage: 220-230 V/1 ph/60Hz
  • Power: 1.45kW
  • Capacity: GN= 6-1/1 containers
                    Max Load capacity: 15 Kg
  • Refrigerant: R404A
  • Installation: 5cm on side and back.
  • Net Weight: 125Kg
  • Gross Weight: 135Kg
  • Warranty: 3 Months


  1. Blast Chilling cycle: 19,5 kg from 90'C up to 3'C in less than 90 minutes.
  2. Blast Freezing cycle: 15 Kg from 90'C up to -18'C in less than 240 minutes.
  3. Soft Chilling (air temperature -2'C)
  4. Hard Chilling (air temperature -20'C)
  5. Holding at +3'C for chilling or -36'C for freezing, automatically activated at the end of each cycle, to save energy and maintain the target temperature (manual activation is also possible)
  6. Freezing (air temperature -36'C)
  7. Turbo cooling: chiller works continuously at the desired temperature; ideal for continuous production.
  8. Control unit provides two large displays to read out; time, core temperature, cycle countdown, alarms, service information.
  9. Two customizable cycles (P1 & P2) for each operating mode, allowing to set the time and air temperature. These programs can be converted into ice-cream specialized cycles (shape maintainance and holding)
  10. All information related to the different operating models are recorded: date, time, cycle, core temperature, holding temperature, HACCP accordance.
  11. Single sensor core probe as standard.
  12. Probe-driven cycles feature ARTE (Algorithm for Remaining Time Estimation) to make planning the activities easier.
  13. Performance guaranteed at ambient temperatures of +40'C
